APsystems offers a range of accessories to ensure proper installation and function of our microinverter systems. See your installation manual or contact our technical support department to determine the proper, certified APsystems accessories for your application.
YC1000-3 Trunk Cable
Part No. Cable-2 (for 2 meter trunk cable for portrait array orientation)
Part No. Cable-4 (for 4 meter trunk cable for landscape array orientation)
YC1000-3 Trunk cable. The 14 AWG cable is sold with two part unique part numbers – with connectors spaced at 2 meters or 4 meters. The varied spacing allows the YC1000-3, Model 208 or 480, to be installed in landscape or portrait.
APsystems DC Extension Cable – For all models
Pair of MC4 Caps (Male and Female)
Part No. MC4 Caps
When only one side of dual YC500 A-NA microinverter is attached to a PV module (Example: odd number of PV modules in circuit). Then these caps should be used to protect the unused MC4 wires on the YC500 A-NA. Also used with our YC1000-3 microinverter model.
- Female cap is used to cover and protect unused MC-4 male connector coming from second pair of YC500 A-NA DC connections.
- Male plug is used to protect unused MC-4 female connector in same application.
